madCAM

Giới thiệu madCAM

madCAM (Mould and Die CAM) là plug in 3D-CAM cho Rhinoceros. Sự phát triển bắt đầu vào năm 1987 với một hệ thống CAM độc lập để sử dụng trong kinh doanh gia đình của chúng tôi để làm khuôn.

Kể từ khi phát hành madCAM như là một bổ trợ cho Rhino vào mùa xuân 2003, trình cắm CAM tích hợp hoàn toàn đầu tiên cho Rhino3D, chúng tôi đã phát triển madCAM để tối ưu hóa việc tích hợp các công cụ CNC mới và điều khiển máy tinh vi hơn với các chức năng mô hình hóa Tê giác.

madCAM cung cấp khả năng tạo các đường chạy dao 3,4 và 5 trục trong Rhinoceros®. Rhino và madCAM cũng phối hợp tuyệt vời như một hệ thống CAM, ngay cả khi công việc thường được thực hiện trong các hệ thống CAD khác, bởi vì Rhino cực kỳ có khả năng nhập tệp ở định dạng 3D khác.

madCAM vẫn được phát triển trong khuôn mẫu của chúng tôi, tạo ra 0ivision, đảm bảo phản hồi ngay lập tức và thiết thực. Bằng cách này, chúng tôi tự tin rằng madCAM đạt được một mức độ kiểm soát và chất lượng gia công vô song. Chúng tôi biết khách hàng của mình có thể tin tưởng vào madCAM vì chúng tôi sử dụng Rhino và madCAM mỗi ngày trong các cơ sở sản xuất của chúng tôi.

Sản phẩm madCAM

madCAM 3X

From 2 1/2-axis to 3-axis milling.Contains what is needed for 3-axis milling inclusive roughing, waterline finishing, planar finishing, pencil tracing, engraving and more.

This version includes advanced, automatic separation of toolpaths. With a suitable strategy for milling of relatively steep and flat areas, calculated from surface normals. We believe this is necessary to obtain high quality and efficient processing.

It is possible to mill inside or inbetween one or more smaller areas by using region curves.






madCAM 3Xtra

Includes everything in madCAM 3X plus automatic remachining and more. This version is aimed for the user that needs additional features for advanced 3-axis milling.

Includes the extra functions needed to automatically and effectively process from a user-defined 3D stock model. By automatically processing areas where there is residual material, it obtains the final finish where previous cutters have not reached material due to cutter size.

It has extra features to avoid or process only the flat areas on a model. To obtain a smoother motion of the machine, there are also functions to remove sharp corners and provide a smoother tool path.






madCAM 4X

Includes everything in madCAM 3X and adds 4-axis milling. When using the "axis of revolution" function included, you can use every function in 3-axis also for 4-axis milling.

As in the 3-axis version, this one also includes advanced automatic separation of toolpaths and uses a suitable strategy for milling of relatively steep and flat areas.

Supports region curves for milling inside or inbetween one or more smaller areas. Includes the extra function to automatically process from a user-defined 3D stock-model.






madCAM 4Xtra

Includes everything in madCAM 4X plus automatic 3-axis and 4-axis remachining and more. This version is aimed for the user that needs additional features for advanced 3-axis and 4-axis milling.

The extra functions needed to automatically and effectively process from a user-defined 3D stock model are added here. By automatically processing areas where there is residual material, it obtains the final finish where previous finishing operations have not reached material due to cutter size.

Included functions for removing sharp corners on the toolpath and provide a smoother motion of the machine.






madCAM 5X

Includes 2 1/2-axis, 3-axis, 4-axis, indexed 5-axis, automatic remachining and more. This version is aimed for the user that needs support for 3-axis, 4-axis and 5-axis milling.

The extra functions needed to automatically and effectively process from a user-defined 3D stock model are included here. By automatically processing areas where there is residual material, it obtains the final finish where previous finishing operations have not reached material due to cutter size.

All features works for 3-axis, simultaneous 4-axis and indexed 5-axis. There are additional options for the axis of revolution function where the user can select the direction of the spindle axis. This makes it possible to create simultaneous 4+1 axis toolpaths.

It has extra features to avoid or process only the flat areas on a model. Included functions for removing sharp corners on the toolpath and provide a smoother motion of the machine.






madCAM 5Xtra

Includes everything in madCAM 5X plus simultaneous 5-axis features like Swarf profiling, perpendicular to surface profiling, part trimming from curves and vectors, 3D drive surface control and more.

This version is aimed for the user that needs additional features for advanced simultaneous 5-axis milling. The extra degree of sophistication for your particular projects.

The drive surface option makes it possible to use any standard toolpath function and keep the cutter perpendicular to the drive surface. The dive surface can be a surface as part of the model or an external surface. This makes it possible to control the cuterdirection in simultaneous 5-axis independent of the shape of the model. The drive surface option works for roughing, waterline finishing, planar finishing, pencil tracing etc.

The swarf profiling is used to create simultaneous 5-axis profiling toolpaths from surface edge curves and keep the cutter parallell to the surface. This function works over several surface edges and can be used on polysurface or solid nurbs models.

The perpendicular to surface profiling is used to create simultaneous 5-axis profiling toolpaths from surface edge curves and keep the cutter perpendicular to the surface. Works on polysurface or solid nurbs models with curves over several surface edges.

The part trimming is used to create simultaneous 5-axis profiling toolpaths from curves and vectors. The cutter direction is controlled by selected vectors or line curves. This function can also be used for simultaneous 5-axis scribing.

5-axis machine setup with kinematics, postprocessor and machine simulation for any kind of 5-axis mashine.

Having this version, you can't miss out on any feature!

So sánh các phiên bản

Compare the product features and see what the different versions of madCAM can do for you!

2 1/2 axis Milling

3X 3Xtra 4X 4Xtra 5X 5Xtra

Profiling

X X X X X X

Pocketing

X X X X X X

Facing

X X X X X X

Drilling

X X X X X X

Engraving

X X X X X X

V-carving

  X X X X X

3 axis Milling

3X 3Xtra 4X 4Xtra 5X 5Xtra

Z-level Pocketing

X X X X X X

Z-level Facing

X X X X X X

Parallel Roughing

X X X X X X

Z-level finishing (Water line finishing)

X X X X X X

Planar finishing

X X X X X X

Planar contour finishing

  X X X X X

Pencil Tracing

X X X X X X

Surface angle limit control (Steep or flat surface machining)

X X X X X X

Along Curves (Engraving)

X X X X X X

Project curves (Engraving)

X X X X X X

Between two curves

X X X X X X

From boundary curves

X X X X X X

Roughing from 3D Stock Model

  X X X X X

Re-roughing

  X   X X X

Z-level remachining

  X   X X X

Planar remachining

  X   X X X

Contour remachining

  X   X X X

V-carving

  X   X X X

4 axis Milling

3X 3Xtra 4X 4Xtra 5X 5Xtra

Indexed 3 + 1-axis (Including all madCAM toolpath functions)

    X X X X

Simultaneous 4-axis Profiling

    X X X X

Simultaneous 4-axis Pocketing

    X X X X

Simultaneous 4-axis Facing

    X X X X

Simultaneous 4-axis Radial-level Pocketing

    X X X X

Simultaneous 4-axis Radial-level Facing

    X X X X

Simultaneous 4-axis Parallel Roughing

    X X X X

Simultaneous 4-axis Radial-level finishing

    X X X X

Simultaneous 4-axis Planar finishing

    X X X X

Simultaneous 4-axis Planar contour finishing

    X X X X

Simultaneous 4-axis Spiral finishing

    X X X X

Simultaneous 4-axis Pencil Tracing

    X X X X

Surface angle limit control (Steep or flat surface machining)

    X X X X

Simultaneous 4-axis Along Curves (Engraving)

    X X X X

Simultaneous 4-axis Project curves (Engraving)

    X X X X

Simultaneous 4-axis Between two curves

    X X X X

Simultaneous 4-axis From boundary curves

    X X X X

Simultaneous 4-axis Roughing from 3D Stock Model

    X X X X

Simultaneous 4-axis Radial-level remachining

      X X X

Simultaneous 4-axis Planar remachining

      X X X

Simultaneous 4-axis Contour remachining

      X X X

Simultaneous 4-axis V-carving

      X X X

5 axis Milling

3X 3Xtra 4X 4Xtra 5X 5Xtra

Indexed 3 + 2 axis (Including all madCAM toolpath functions)

        X X

Simultaneous 5 axis from axis of revolution
(Including all madCAM toolpath functions except re-roughing)

        X X

Simultaneous 5-axis Drive Surface Offset-level Pocketing

          X

Simultaneous 5-axis Drive Surface Offset-level Facing

          X

Simultaneous 5-axis Drive Surface U-V Roughing

          X

Simultaneous 5-axis Drive Surface Offset-level finishing

          X

Simultaneous 5-axis Drive Surface U-V finishing

          X

Simultaneous 5-axis Drive Surface border contour finishing

          X

Simultaneous 5-axis Closed Drive Surface spiral finishing

          X

Simultaneous 5-axis Drive Surface Pencil Tracing

          X

Simultaneous 5-axis Drive Surface angle limit control

          X

Simultaneous 5-axis SWARF Profiling from surface edge curves

          X

Simultaneous 5-axis Profiling perpendicular to surface

          X

Simultaneous 5-axis Part trimming from curves and vectors

          X

Regions and Boundaries

3X 3Xtra 4X 4Xtra 5X 5Xtra

Box work piece

X X X X X X

Region Curves

X X X X X X

Tool path Clipping planes

X X X X X X

User defined 3D stock models (Except simultaneous 5-axis drive surface)

  X X X X X

Drive Surface calculation height and depth option

          X

Regions from drive surface borders (trim curves)

          X

Drive Surface tool path clipping levels option.

          X

Simultaneous 5-axis vertical angle limit option

          X

Toolpath editing

3X 3Xtra 4X 4Xtra 5X 5Xtra

Transform and copy as ordinary Rhino curves (The toolpath curves are saved in Rhino as standard Rhino curves and can be transformed by using standard Rhino commands. It is also possible to edit control points on a toolpath curve.)

X X X X X X

Simulation

3X 3Xtra 4X 4Xtra 5X 5Xtra

3-axis Material removal simulation

X X X X X X

3-axis Tool holder collision simulation

X X X X X X

4 axis machine parts simulation

    X X X X

5-axis machine parts simulation

        X X

Custom machine

3X 3Xtra 4X 4Xtra 5X 5Xtra

4-axis machine setup

    X X X X

5-axis machine setup

        X X

Custom STL files support for machine parts simulation

  X X X X X

External DLL support for machine kinematics

          X

Post Processor

3X 3Xtra 4X 4Xtra 5X 5Xtra

Customizable post processors

X X X X X X

4-axis output

    X X X X

5-axis output

        X X

5-axis APT output

        X X

Chính sách cấp phép

Single license, vĩnh viễn.

Liên hệ MUA madCAM bản quyền

Quý khách hàng vui lòng liên lạc chuyên viên tại HCM, HN và các tỉnh khác hoặc qua email sales@pacisoft.com với thông tin đầy đủ và số lượng sản phẩm để có báo giá tốt nhất. Cam kết mức giá cạnh tranh và hỗ trợ tuyệt vời. Hotline (024) 3915 6886 hoặc (028) 36100 816.
